Hangzhou Evershine Pneumatic Import & Export Co., Ltd. is one of the leading manufacturers and suppliers of digital air pressure regulator in China. With abundant experience, we are committed to providing high quality pneumatic components to global clients. Welcome to wholesale custom made digital air pressure regulator from our factory. Also, OEM service is available.
Model Indication Method
|
Model |
Basic type |
Air Control Type |
||||
|
IR10 □0 |
IR20 □0 |
R30 □0 |
IR212 0 |
IR312 0 |
||
|
IR |
200 0 □ 02 □ □ □ □ |
|||||
|
① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ |
||||||
|
Mark |
Content |
|||||
|
①Valve Size |
1 |
IR1000 series |
||||
|
2 |
IR2000 series |
|||||
|
3 |
IR3000 series |
|||||
|
②Setting Method |
0 |
Basic type (manual) |
||||
|
1 |
Air control type (IR2000/3000) |
|||||
|
③Setting Pressure Range Note1 |
0 |
IR1000/2000: 0.005-0.2MPa |
IR3000:0.01-0.2MPa |
|||
|
1 |
IR1000/2000: 0.01-0.4MPa |
IR3000:0.01-0.4MPa |
||||
|
2 |
IR1000/2000: 0.01-0.8MPa |
IR3000:0.01-0.8MPa |
||||
|
④Thread Type |
No mark |
Rc |
||||
|
N |
NPT note 2 |
|||||
|
F |
G note 2 |
|||||
|
⑤Tube Diameter |
01 |
1/8 |
||||
|
02 |
1/4 |
|||||
|
03 |
3/8 |
|||||
|
04 |
1/2 |
|||||
|
⑥Accessories |
No mark |
None |
||||
|
B |
Bracket |
|||||
|
G note 3 |
With pressure gauge |
|||||
|
⑦Mark 1 |
No mark |
- |
||||
|
T |
For high temperature environment (-5~100℃) (Max.80℃ when equipped with pressure gauge) |
|||||
|
L note 4 |
For low temperature environment (-30~60℃) |
|||||
|
⑧Mark 2 |
No mark |
- |
||||
|
R note 5 |
Pressure gauge, bracket and nameplate are installed on the back |
|||||
|
⑨Customized specifications Note 6 |
X1 |
Grease-free specifications |
||||
|
X170 |
Corresponding to the new modular connection (with modular connector) |
|||||
|
X465 □ |
With digital pressure switch (ISE30A) |
|||||
Note 1: Air control type is only available in IR2120/IR3120
Note 2: Quasi-standard product
Note 3: "G" cannot be selected for low temperature environments
Note 4: Except IR1000, IR3000 can't combine with "L" and "X1"
Note 5: The standard installation position is SUP side on the left, OUT side on the right, the pressuregauge can be seen from the front, and the bracket is on the back
Note 6: Clean room specifications can be matched with connector models (10-). Copper-free andfluorine-free specifications can be matched with connector models (20-). Ozone-resistant specifications can be matched with connector models (80-). IR1000 and IR2000 are available in manifold specifications.
(Except IR2120 and IR3000)
Specification
|
Max. Supply Pressure |
MAX.1.0 MPa |
||||
|
Min. Supply Pressure Note 1 |
Setting pressure +0.05MPa |
Setting pressure +0.1MPa |
Setting pressure +0.05MPa |
Setting pressure +0.1MPa |
|
|
Setting Pressure Range |
IR1000:0.005~0.2MPa IR1010:0.01~0.4MPa IR1020:0.01~0.8MPa |
IR2000:0.005~0.2MPa IR2010:0.01~0.4MPa IR2020:0.01~0.8MPa |
IR3000:0.01~0.2MPa IR3010:0.01~0.4MPa IR3020:0.01~0.8MPa |
0.01~0.8MPa |
0.01~0.8MPa |
|
Input Signal Pressure Note 2 |
0.01~0.8MPa |
0.01~0.8MPa |
|||
|
Sensitivity Note 3 |
Within 0.2% of full range |
||||
|
Repeatability Note 3 |
Within 0.5% of full range |
||||
|
Straightness note 4 |
Within 1% of full range |
||||
|
Air Consumption Note 5 (When supply pressure is 1.0 MPa) |
Within 1% of full range |
Within 4.4L/min(ANR) |
Within 11.5L/min(ANR) |
Within 4.4L/min(ANR) |
Within 11.5L/min(ANR) |
|
Tube Diameter |
Rc1/8 |
Rc1/4 |
Rc1/4, 3/8, 1/2 |
Rc1/4 |
Rc1/4,3/8,1/2 |
|
Pressure Connecting Diameter |
Rc1/8 (2 points) |
||||
|
Environment Temperature and Fluid Temperature |
5~60℃(no frozen) |
||||
|
Weight (KG) |
0.14 |
0.30 |
0.64 |
0.35 |
0.71 |
Dimdimensions
Video
FAQ
1. What is a precision air pressure regulator used for?
It is used to maintain a stable and accurately controlled outlet pressure in pneumatic systems where precise pressure adjustment is required.
2. How do I adjust the outlet pressure?
The outlet pressure can be finely adjusted using the regulator knob. Turn the knob gradually while monitoring the pressure gauge until the required pressure is reached.
3. What applications require a precision air pressure regulator?
It is commonly used in precision pneumatic equipment, automation machinery, testing systems, air tools and applications requiring stable pressure control.
