Hangzhou Evershine Pneumatic Import & Export Co., Ltd. is one of the leading manufacturers and suppliers of high pressure pneumatic regulator in China. With abundant experience, we are committed to providing high quality pneumatic components to global clients. Welcome to wholesale custom made high pressure pneumatic regulator from our factory. Also, OEM service is available.
Pressure Adjustment
Ordering Code
Feature
- The high pressure reducing valve is a component of the pneumatic control valve. Its main function is to reduce the pressure of the gas source and stabilize it to fixed value so that the control valve can obtain a stable gas source power for regulation and control
- The pressure reduction effect is reliable, and the outlet pressure is not affected by the inlet pressure and flow rate. It reduces both dynamic pressure and static pressure, and can keep the set outlet pressure constant
- Easy to adjust, just adjust the adjusting screw of the pilot valve to get a stable outlet pressure
- Good energy-saving effect, the valve body adopts a full-channel streamlined direct-flow design, with small pressure loss, large flow, small volume and light weight
- Long service life, important parts are made of special materials, basically maintenance-free
Data Sheet
|
Model |
QTYH-08 |
QTYH-10 |
QTYH-15 |
QTYH-20 |
QTYH-25 |
QTYH-32 |
QTYH-40 |
QTYH-50 |
|
Working medium |
Compressed air, nitrogen, inert gas |
|||||||
|
Port Size |
G1/4 |
G3/8 |
G1/2 |
G3/4 |
G1 |
G1 3/8 |
G11/2 |
G2 |
|
Pressure regulating range |
1.5~35Bar |
|||||||
|
Max. Input Pressure |
4MPa |
|||||||
|
Operating Temperature Range |
-5~60℃ |
|||||||
Dimension
Video
FAQ
1. What is the maximum pressure rating of a High Pressure Pneumatic Regulator?
The maximum inlet pressure depends on the specific model and configuration. Always select a regulator according to the required inlet pressure, outlet pressure and application conditions.
2. How does a high-pressure pneumatic regulator improve system performance?
It reduces high inlet pressure to a controlled outlet pressure, helping protect downstream components and maintain stable operation even when the supply pressure fluctuates.
3. What gases can be used with a High Pressure Pneumatic Regulator?
It is primarily designed for compressed air and compatible non-corrosive gases. For special gases or demanding applications, the media compatibility and pressure specifications should be confirmed before use.
